Tubular Low Profile Push/Pull Solenoid

duty cycle

1 (100%)

1/2 (50%)

1/4 (25%)

1/10 (10%)

maximum "ON” time, (Sec.)

infinite (∞ )

100

30

10

watts

4.5

9

18

45

approximate ampere turns

325

460

645

1025

coil wire size (AWG)

coil resistance (Ω)

volts DC

volts DC

volts DC

volts DC

24

0.8

1.8

2.6

3.6

5.7

25

1.3

2.3

3.2

4.5

7.1

26

1.9

2.9

4.1

5.8

9.2

27

3.0

3.6

5.1

7.2

11.4

28

4.7

4.6

6.5

9.1

14.5

29

7.3

5.7

8.1

11.4

18.1

30

11.9

7.3

10.4

14.6

23.2

31

18.9

9.3

13.1

18.4

29.2

32

28.4

11.4

16.2

22.7

36.1

33

46.0

14.5

20.6

28.9

45.9

34

72.3

18.4

26.1

36.6

58.1

35

117

23.3

33.0

46.3

73.6

36

193

29.3

41.5

58.1

92.4

37

337

39.8

56.3

79.0

126

38

434

45.7

64.7

90.8

144

39

756

59.8

84.6

119

189

40

1197

76.2

108

151

240

41

1912

92.5

131

184

292

S-05-125 Low-Profile Solenoid Features and Applications

Key Features

Push / Pull Type low-profile construction; 1.25 in (31.8 mm) diameter; 0.50 in (12.7 mm) body length; 2.34 oz (66.3 g) total weight; four duty-cycle ratings; and multiple coil windings for a range of DC operating voltages.

Typical Applications

The S-05-125 may be considered for latches, locks, valves, indexing, dispensing, positioning and other short-stroke push/pull actuation assemblies. Verify force, stroke, duty cycle, heat sinking and environmental requirements for the final design.

For mechanical dimensions and performance information, see additional S-05-125 data or download the PDF datasheet, or use the 3D STEP model. For application assistance, contact Magnetic Sensor Systems.
