Push Type Tubular Solenoid

duty cycle

1 (100%)

1/2 (50%)

1/4 (25%)

1/10 (10%)

maximum "ON” time, (Sec.)

infinite (∞ )

180

500

10

watts

4.5

9

18

45

approximate ampere turns

700

990

1400

2210

coil wire size (AWG)

coil resistance (Ω)

volts DC

volts DC

volts DC

volts DC

25

0.93

2.1

3.0

4.2

6.6

26

1.67

2.7

3.9

5.5

8.6

27

2.33

3.3

4.7

6.6

10.5

28

4.36

4.4

6.2

8.8

13.8

29

5.81

5.0

7.1

10.0

15.8

30

11.2

7.1

10.1

14.2

22.5

31

15.2

8.1

11.4

16.2

25.5

32

23.4

9.9

14.0

19.8

31.2

33

39.8

13.4

18.9

26.8

42.3

34

65.2

17.2

24.4

34.5

54.4

35

106

22.3

31.5

44.6

70.4

36

158

26.2

37.1

52.4

82.7

37

261

35.0

49.5

70.0

111

38

381

42.5

60.0

84.9

134

39

710

55.2

78.0

110

174

40

1007

67.5

95.4

135

213

41

1566

82.3

117

165

260

42

2417

104

147

207

327

S-16-50-H Tubular Solenoid Features and Applications

Key Features

0.50 in (12.7 mm) diameter body; 1.63 in (41.4 mm) body length; 1.18 oz (33.5 g) total weight; published duty-cycle and DC winding options.

Typical Applications

The S-16-50-H may be considered for indexing pins, ejectors, dispensing mechanisms, automated fixtures, sorting equipment and other short-stroke push-actuation assemblies. Verify force, stroke, duty cycle, heat sinking and environmental requirements for the final design.

For mechanical details and performance information, see the additional S-16-50-H data, PDF datasheet, or the 3D STEP model. For application assistance, contact Magnetic Sensor Systems.
