Push Type Open C-Frame Solenoid

duty cycle

1 (100%)

1/2 (50%)

1/4 (25%)

1/10 (10%)

maximum "ON” time, (Sec.)

infinite (∞ )

100

15

10

watts

5

10

20

40

approximate ampere turns

1060

1500

2120

3000

coil wire size (AWG)

coil resistance (Ω)

volts DC

volts DC

volts DC

volts DC

23

1.8

3.0

4.2

6.0

8.5

24

2.7

3.7

5.2

7.3

10.4

25

4.4

4.7

6.6

9.4

13.3

26

7.4

6.1

8.6

12.2

17.2

27

11.0

7.4

10.5

14.8

21.0

28

18.7

9.7

13.7

19.3

27.3

29

30.3

12.3

17.4

24.6

34.8

30

46.1

15.2

21.5

30.4

42.9

31

76.9

19.6

27.7

39.2

55.5

32

117

24.2

34.2

48.4

68.4

33

185

30.4

43.0

60.8

86.0

34

286

37.8

53.5

75.6

107

35

477

48.8

69.1

97.7

138

36

705

59.4

84.0

119

168

37

1105

74.3

105

149

210

38

1643

90.6

128

181

256

39

2915

121

171

241

341

40

4610

152

215

304

429

Open-Frame Solenoid Features and Applications

Key Features

The S-17-85-QH is a push-type open C-frame linear solenoid measuring 0.84 x 0.92 x 1.75 in [21.3 x 23.4 x 44.5 mm]. The tables above provide duty-cycle, maximum on-time, power, coil resistance and DC voltage options for selecting a suitable winding and operating condition.

Typical Applications

This open-frame push solenoid may be considered for latches, gates, release mechanisms, dispensing equipment, office machines, sorting systems, industrial controls and other short-to-moderate-stroke linear actuation assemblies. Verify force, stroke, duty cycle, heat sinking and environmental requirements for the final design.

For additional engineering information, see the mechanical dimensions and force curves, PDF datasheet and 3D STEP model, or contact Magnetic Sensor Systems.
